Core drill bits HSS Bohre
Bohre HSS core drill bits. These drills are capable of working at high RPM and vibration loads. Thanks to the optimum angle of laser sharpening of the cutting teeth, high productivity is achieved while maintaining the drill life.
Advantages of Bohre HSS core drill bits
Tooth geometry
The bohre™ aligned geometry of the end teeth allows for extended drill life without loss of drilling efficiency
Sharpening of blades
Unique blade sharpening and bohre™ chip groove geometry ensure efficient and accurate drilling
Pilot
Ensures drill bit alignment, regulates coolant supply and pushes out the drilled core
Weldon universal shank
Fits Weldon 19.05 spindle magnet machines from all manufacturers
Video overview of Bohre HSS core drill bits
Bohre HSS core drill bits
L = 30 mm
| Item number | d (mm) |
|---|---|
| KB010044 | 12 |
| KB010045 | 13 |
| KB010083 | 14 |
| KB010046 | 15 |
| KB010084 | 16 |
| KB010047 | 17 |
| KB010048 | 18 |
| KB010093 | 19 |
| KB010049 | 20 |
| KB010094 | 21 |
| KB010086 | 22 |
| KB010050 | 23 |
| KB010290 | 24 |
| KB010051 | 25 |
| KB010052 | 26 |
| KB010168 | 27 |
| KB010053 | 28 |
| KB010291 | 29 |
| KB010054 | 30 |
| KB010292 | 31 |
| KB010055 | 32 |
| KB010293 | 33 |
| KB010294 | 34 |
| KB010295 | 35 |
| KB010229 | 36 |
| KB010296 | 37 |
| KB010062 | 38 |
| KB010297 | 39 |
| KB010230 | 40 |
| KB010298 | 41 |
| KB010299 | 42 |
| KB010300 | 43 |
| KB010301 | 44 |
| KB010302 | 45 |
| KB010303 | 46 |
| KB010304 | 47 |
| KB010305 | 48 |
| KB010306 | 49 |
| KB010268 | 50 |
| KB010307 | 51 |
| KB010308 | 52 |
| KB010309 | 53 |
| KB010310 | 54 |
| KB010311 | 55 |
| KB010312 | 56 |
| KB010313 | 57 |
| KB010314 | 58 |
| KB010315 | 59 |
| KB010316 | 60 |
| KB010317 | 61 |
| KB010318 | 62 |
| KB010319 | 63 |
| KB010320 | 64 |
| KB010321 | 65 |
L = 55 mm
| Item number | d (mm) |
|---|---|
| KB010020 | 12 |
| KB010087 | 13 |
| KB010063 | 14 |
| KB010067 | 15 |
| KB010088 | 16 |
| KB010092 | 17 |
| KB010068 | 18 |
| KB010069 | 19 |
| KB010070 | 20 |
| KB010095 | 21 |
| KB010071 | 22 |
| KB010072 | 23 |
| KB010073 | 24 |
| KB010074 | 25 |
| KB010322 | 26 |
| KB010075 | 27 |
| KB010076 | 28 |
| KB010323 | 29 |
| KB010089 | 30 |
| KB010077 | 31 |
| KB010324 | 32 |
| KB010078 | 33 |
| KB010269 | 34 |
| KB010079 | 35 |
| KB010171 | 36 |
| KB010325 | 37 |
| KB010080 | 38 |
| KB010172 | 39 |
| KB010326 | 40 |
| KB010327 | 41 |
| KB010169 | 42 |
| KB010328 | 43 |
| KB010329 | 44 |
| KB010330 | 45 |
| KB010331 | 46 |
| KB010332 | 47 |
| KB010333 | 48 |
| KB010334 | 49 |
| KB010335 | 50 |
| KB010270 | 51 |
| KB010271 | 52 |
| KB010336 | 53 |
| KB010272 | 54 |
| KB010081 | 55 |
| KB010264 | 56 |
| KB010265 | 57 |
| KB010266 | 58 |
| KB010337 | 59 |
| KB010267 | 60 |
| KB010338 | 61 |
| KB010339 | 62 |
| KB010340 | 63 |
| KB010341 | 64 |
| KB010342 | 65 |
L = 80 mm
| Item number | d (mm) |
|---|---|
| KB010343 | 18 |
| KB010344 | 19 |
| KB010345 | 20 |
| KB010346 | 21 |
| KB010347 | 22 |
| KB010348 | 23 |
| KB010349 | 24 |
| KB010350 | 25 |
| KB010351 | 26 |
| KB010352 | 27 |
| KB009973 | 28 |
| KB010353 | 29 |
| KB010354 | 30 |
| KB010355 | 31 |
| KB010356 | 32 |
| KB010357 | 33 |
| KB010358 | 34 |
| KB010359 | 35 |
| KB010360 | 36 |
| KB010361 | 37 |
| KB010362 | 38 |
| KB010363 | 39 |
| KB010364 | 40 |
| KB010365 | 41 |
| KB010366 | 42 |
| KB010367 | 43 |
| KB010368 | 44 |
| KB010369 | 45 |
| KB010370 | 46 |
| KB010371 | 47 |
| KB010372 | 48 |
| KB010373 | 49 |
| KB010374 | 50 |
| KB010375 | 51 |
| KB010376 | 52 |
| KB010377 | 53 |
| KB010378 | 54 |
| KB010379 | 55 |
| KB010380 | 56 |
| KB010381 | 57 |
| KB010382 | 58 |
| KB010383 | 59 |
| KB010384 | 60 |
| KB010385 | 61 |
| KB010386 | 62 |
| KB010387 | 63 |
| KB010388 | 64 |
| KB010389 | 65 |
L = 110 mm
| Item number | d (mm) |
|---|---|
| KB010566 | 18 |
| KB010567 | 19 |
| KB010568 | 20 |
| KB010569 | 21 |
| KB010570 | 22 |
| KB010571 | 23 |
| KB010572 | 24 |
| KB010573 | 25 |
| KB010574 | 26 |
| KB010575 | 27 |
| KB010576 | 28 |
| KB010577 | 29 |
| KB010578 | 30 |
| KB010579 | 31 |
| KB010580 | 32 |
| KB010581 | 33 |
| KB010582 | 34 |
| KB010583 | 35 |
| KB010584 | 36 |
| KB010585 | 37 |
| KB010586 | 38 |
| KB010587 | 39 |
| KB010588 | 40 |
| KB010589 | 41 |
| KB010590 | 42 |
| KB010591 | 43 |
| KB010592 | 44 |
| KB010593 | 45 |
| KB010594 | 46 |
| KB010595 | 47 |
| KB010596 | 48 |
| KB010597 | 49 |
| KB010598 | 50 |
| KB010599 | 51 |
| KB010600 | 52 |
| KB010601 | 53 |
| KB010602 | 54 |
| KB010603 | 55 |
| KB010604 | 56 |
| KB010605 | 57 |
| KB010606 | 58 |
| KB010607 | 59 |
| KB010608 | 60 |
| KB010609 | 61 |
| KB010610 | 62 |
| KB010611 | 63 |
| KB010612 | 64 |
| KB010613 | 65 |
Core drill sets for metal
| Item number | Description |
|---|---|
| KB003623 | 12,14,16,18,20,22 mm x50, Weldon 19, pin 6.34x103 |
| KB003624 | 13.15.17.19.21.23 mm x50, Weldon 19, pin 6.34x103 |
| KB003625 | 24,26,28,30,32,34 mm x50, Weldon 19, pin 6.34x103 |
| KB003626 | 25,27,29,31,33,35 mm x50, Weldon 19, pin 6.34x103 |
